Cisco UCSC-PSU1-1600W 1600W AC Hot-Swap Server Power Supply
New
Photos are representative. Refurbished units may show light cosmetic wear; all ports and PSUs tested.
CiscoCisco UCS
Cisco UCSC-PSU1-1600W 1600W AC Hot-Swap Server Power Supply
- Part number
- UCSC-PSU1-1600W=
- 1600W output supports demanding UCS compute configurations
- 200–240VAC input suits high-voltage data-center feeds
- 12VDC output matches UCS server power architecture
- 80 PLUS Platinum reduces PSU conversion losses
- 80ms hold-up supports short input disturbances
- RSP2 form factor fits supported UCS server bays
CONDITION
Ideal for
UCS C-Series, C220, C240, High-Power Servers, Data Centers, Server Rooms
Cisco UCSC-PSU1-1600W provides 1600W AC power for compatible Cisco UCS C-Series rack servers and redundant power configurations Server Power Supply
Overview
Cisco UCS 1600W AC power supply for C-Series rack servers, with 200–240VAC nominal input and 12VDC output architecture.
Application & Use Cases
- UCS C220/C240 server power
- High-power rack-server deployments
- Redundant PSU installations
- Data-center compute infrastructure
Features
- 1600W AC output
- Platinum efficiency
- RSP2 form factor
- IEC320 C14 input connector
Key Specifications
- Power Rating: 1600W
- Input Voltage: 200–240VAC nominal
- Input Range: 180–264VAC
- Frequency: 50–60Hz
- Maximum Input Current: 9.5A at 200VAC
- Inrush Current: 30A
- Hold-Up Time: 80ms at 1600W
- Output: 12VDC
- Efficiency: 80 PLUS Platinum
- Form Factor: RSP2
- Input Connector: IEC320 C14
No compatible accessories listed for this product.
| Product Series | UCS C-Series |
| Product Type | Power Supply |
| Quantity of Fans | 1 |
| Input Voltage | 200-240V |
| Max. Output Power | 1600 Watts |
| Efficiency | 90 % |
| Form Factor | Internal |
| Compliance Standards | 80 Plus Platinum |
