Cisco IE-2000-4T-B-RF IE 2000 Series 4-Ports FE Switch
Refurbished
![IE-2000-4T-B-RF]()
![IE-2000-4T-B-RF]()
Photos are representative. Refurbished units may show light cosmetic wear; all ports and PSUs tested.
CiscoCisco Industrial Switches
Cisco IE-2000-4T-B-RF IE 2000 Series 4-Ports FE Switch
- Part number
- IE-2000-4T-B-RF
- 6 Fast Ethernet copper interfaces
- LAN Base industrial switching feature set
- Dual copper uplink interfaces
- 802.1Q VLAN segmentation support
- RSTP/STP loop prevention
- IGMP snooping multicast filtering
CONDITION
Ideal for
Industrial control cabinets, PLC networks, factory automation, OT access
Cisco IE-2000-4T-B-RF - Industrial Ethernet IE 2000 Series 6x FE Ports 10/100Base-TX Layer 2 Managed Fast Ethernet Network Switch
Overview
Cisco IE 2000 industrial managed switch with 6 Fast Ethernet copper ports and LAN Base software.
Application & Use Cases
- Industrial Ethernet access connectivity
- PLC, HMI and industrial controller networks
- Compact DIN-rail control cabinets
- Industrial VLAN and segmentation deployments
Features
- 4 × 10/100BASE-T downlinks
- 2 × 10/100BASE-T uplinks
- LAN Base feature set
- Managed Layer 2 switching
- Industrial ruggedized design
- DIN-rail mounting
- REP support
- QoS and VLAN support
Key Specifications
- Downlinks: 4 × 10/100BASE-T
- Uplinks: 2 × 10/100BASE-T
- Total Ports: 6
- Port Connector: RJ-45
- Port Speed: 10/100 Mbps
- Duplex: Full/Half duplex
- Software: LAN Base
- Switch Type: Managed industrial Ethernet
- VLAN: 802.1Q
- QoS: Supported
- STP: Supported
- RSTP: Supported
- IGMP Snooping: Supported
- Port Security: Supported
- RSPAN: Supported
- Storm Control: Broadcast/multicast/unicast
- Management: Cisco IOS
- Mounting: DIN rail
- Series: Cisco IE 2000
No compatible accessories listed for this product.
| Product Line | Industrial Ethernet |
| Product Series | IE-2000 |
| Product Type | Ethernet Switch |
| POE/POE+ Supports | Non-PoE |
| USB Port | No |
| Console Management Port | Yes |
| Quantity of Fixed Ports/Expansion Slots | 6 |
| Quantity of Network Ports | 6 |
| Stacking Port | No |
| Ethernet Standard | Fast Ethernet |
| Media Standard | Optical Fiber |
| Technology Standard | 10/100Base-TX |
| Supported Layer Standard | Layer 2/3 |
| Manageable | Yes |
| MAC Address Table Capacity | 8000 MAC Addresses |
| Jumbo Frames | 9000 Bytes |
| Form Factor | Desktop PC,Rail-mountable |
| Airflow Direction | Side-to-Side Airflow |
| Source of Power | DC Power Supply |
