Cisco C9300X-48TX-A 9300 Catalyst 48-Ports Unmanaged 10GbE Switch
New
Photos are representative. Refurbished units may show light cosmetic wear; all ports and PSUs tested.
CiscoCisco Catalyst 9300 Switches
Cisco C9300X-48TX-A 9300 Catalyst 48-Ports Unmanaged 10GbE Switch
- Part number
- C9300X-48TX-A
- 48 multigigabit ports support scalable copper endpoint speeds
- 10Gbps interfaces support high-bandwidth endpoint connectivity
- StackWise-1T provides high-capacity switch stacking
- StackPower+ enables shared power architecture between switches
- Modular uplinks support flexible high-speed aggregation designs
- Network Advantage provides the advanced software tier
CONDITION
Ideal for
Enterprise access; campus distribution; Wi-Fi 6E; 10G servers; data centers; multigigabit LAN; SD-Access; high-speed access
Cisco C9300X-48TX-A Catalyst 9300 C9300X-48TX 48x Ports 10GbE Layer 2 Unmanaged Gigabit Ethernet Network Switch
Overview
Cisco Catalyst 9300X 48-port 10G multigigabit data switch with modular uplinks and Network Advantage.Application & Use Cases
- 10G enterprise access
- Campus distribution
- Wi-Fi 6E access infrastructure
- High-speed server access
- Data-center switching
- Multigigabit campus networks
Features
- 48× 10G multigigabit copper
- 100M/1G/2.5G/5G/10G
- Modular uplinks
- StackWise-1T
- StackPower+
- Network Advantage
Key Specifications
- Ports: 48
- Rates: 100M/1/2.5/5/10G
- Interface: RJ45 multigigabit
- Uplinks: Modular
- Stacking: StackWise-1T
- License: Network Advantage
No compatible accessories listed for this product.
| Product Line | Catalyst |
| Product Series | 9300X |
| Model | C9300X-48TX |
| Product Type | Ethernet Switch |
| POE/POE+ Supports | Non-PoE |
| USB Port | Yes |
| Console Management Port | Yes |
| Quantity of Fixed Ports/Expansion Slots | 49 |
| Quantity of Network Ports | 48 |
| Uplink Port | Yes |
| Modular Expansion | Yes |
| Stacking Port | Yes |
| Quantity of Expansion Slots | 1 |
| Ethernet Standard | Gigabit Ethernet |
| Media Standard | Twisted Pair |
| Technology Standard | 10/100/1000Base-T |
| Supported Layer Standard | Layer 2/3 |
| Manageable | Yes |
| MAC Address Table Capacity | 32000 MAC Addresses |
| Jumbo Frames | 9198 Bytes |
| Form Factor | Rack-mountable |
| Compliance Standards | RoHS,WEEE |
| Airflow Direction | Front-to-Back Airflow |
| Source of Power | AC Power Supply |
| Redundant Source of Power | Yes |
| Power Rating | 715 Watts |
| Installed PSU | 1 |
